ANTENA UBIQUITI LTU Pro

Šifra: 21091201 PN: LTU-PRO Vrijeme dostave: 1 dan(a)

Ilidža

M. Dvor

538.98 KM

Cijena bez popusta: 579.55 KM

5 GHz PtMP LTU Client with advanced RF performance, functions in a PtMP environment with the LTU-Rocket as the BaseStation.
5 GHz, 25+ km link range
900+ Mbps throughput*
Dedicated spectral analysis radio
Integrated radome
Note. Compatible with LTU devices only.
*FW version 2.3.0 and later.

Troškovi dostave

10 KM za sve destinacije u BiH

Obavještavamo vas da uprkos našim najboljim namjerama ne možemo garantovati da objavljene informacije i slike ne sadrže nedostatke i greške koje ne mogu biti pravna osnovica za tužbu.

Specifikacija

Opcija	Vrijednost
Proizvođač	Ubiquiti
Garancija	12 mjeseci
Vrsta	Router antena
Snaga	-

Opis

LTU Professional

Mechanical
Dimensions	316.5 x 316.5 x 174.3 mm (12.46 x 12.46 x 6.86")
Weight	1.3 kg (2.87 lb)
Enclosure material	UV-stabilized polycarbonate
Mounting	Pole mount (Kit included)
Wind loading	150 N at 200 km/h (33.72 lbf at 125 mph)
Wind survivability	200 km/h (125 mph)
Hardware
Networking interface	(1) GbE RJ45 port
Power method	24V Passive PoE (Pairs 4, 5+; 7, 8-)
Power supply	24V, 0.5A Gigabit PoE adapter (Included)
Supported voltage range	22–26V DC
Max. power consumption	9W
ESD/EMP protection	Air/contact: ± 24kV
Operating temperature	-40 to 60° C (-40 to 140° F)
Operating humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC
Software
Modes	PtMP CPE, PtP* *1.5.1 and later 1.5.x series firmware.
Services	SNMP, SSH, dynamic DNS, webserver, remote log, ping watchdog
Utilities	airView®, speed test, alignment, discovery, ping, traceroute, cable test, constellation
Auto distance adjustment	Yes
Auto power adjustment	Yes
Network	Bridge/Router* mode *Router mode is available in PtMP CPE mode only.
Security	Yes
Statical reporting	Yes
Management interface	Bluetooth management for easy setup over UISP App WEB UI
Minimum software requirements	Any modern web browser iOS™ or Android™ based smartphone
System
Maximum throughput	900+ Mbps* *FW version 2.3.0 and later.
Encryption	WPA2-PSK (AES)
Uplink/downlink ratio	25/75, 33/67, 50/50
RF
Operating frequency* US/CA U-NII-1 U-NII-2A U-NII-2C U-NII-3 EU Worldwide	5150 - 5250 MHz 5250 - 5350 MHz 5470 - 5725 MHz 5725 - 5850 MHz 2400 - 2483.5 MHz 5150 - 5875 MHz 2400 - 2483.5 MHz 4800 - 6200 MHz *Depends on regulatory region.
Max. conducted TX power	22 dBm (per chain)
Channel bandwidth	10/20/30/40/50/60/80/100 MHz* *FW version 2.3.0 and later.
Antenna gain	24 dBi
Beamwidth	14°
Sidelobe level	-10 dB
Front-to-back ratio	27 dB
